Hi,
coming from this thread I opened an own issue as @dcsapak suggested.
I have issues with the video output when passing through the latest Blackwell Generation RTX Pro 6000 Max Q Version. The GPU passthrough works fine, the GPU is detected in Windows and Ubuntu Server. In Windows 11 there is no Code 43, I use the latest 580 driver from Nvidia Website. In the Nvidia Manager on the Windows VM the GPU is also available and shows the name of my Display but there is no video output, the screen is just black (but backlight is own, so their is a signal).
Same goes for ubuntu server 24.04 version. The GPU is recognized with the latest Nvidia driver from there website (I downloaded and run the abc.run file from nvidia site and selected the MIT Version of the driver, proprietary is not working for that gpu). Here are some outputs:
System is Proxmox 9.0.6 with zfs install:
coming from this thread I opened an own issue as @dcsapak suggested.
I have issues with the video output when passing through the latest Blackwell Generation RTX Pro 6000 Max Q Version. The GPU passthrough works fine, the GPU is detected in Windows and Ubuntu Server. In Windows 11 there is no Code 43, I use the latest 580 driver from Nvidia Website. In the Nvidia Manager on the Windows VM the GPU is also available and shows the name of my Display but there is no video output, the screen is just black (but backlight is own, so their is a signal).
Same goes for ubuntu server 24.04 version. The GPU is recognized with the latest Nvidia driver from there website (I downloaded and run the abc.run file from nvidia site and selected the MIT Version of the driver, proprietary is not working for that gpu). Here are some outputs:
System is Proxmox 9.0.6 with zfs install:
Code:
root@titan:~# cat /etc/kernel/cmdline
root=ZFS=rpool/ROOT/pve-1 boot=zfs intel_iommu=on initcall_blacklist=sysfb_init vfio_iommu_type1.allow_unsafe_interrupts=1 vfio-pci.ids=10de:2bb4,10de:22e8
Code:
root@titan:~# cat /etc/modules
# /etc/modules is obsolete and has been replaced by /etc/modules-load.d/.
# Please see modules-load.d(5) and modprobe.d(5) for details.
#
# Updating this file still works, but it is undocumented and unsupported.
vfio
vfio_iommu_type1
vfio_pci
vfio_virqfd
Code:
root@titan:~# ls /etc/modprobe.d/
blacklist.conf intel-microcode-blacklist.conf pve-blacklist.conf vfio.conf zfs.conf
root@titan:~# cat /etc/modprobe.d/*
blacklist radeon
blacklist nouveau
blacklist nvidia
blacklist snd_hda_intel
blacklist amd76x_edac
blacklist vga16fb
blacklist rivafb
blacklist nvidiafb
blacklist rivatv
# The microcode module attempts to apply a microcode update when
# it autoloads. This is not always safe, so we block it by default.
blacklist microcode
# This file contains a list of modules which are not supported by Proxmox VE
# nvidiafb see bugreport https://bugzilla.proxmox.com/show_bug.cgi?id=701
blacklist nvidiafb
options vfio_iommu_type1 allow_unsafe_interrupts=1
options kvm ignore_msrs=1 report_ignored_msrs=0
options vfio-pci ids=10de:2bb4,10de:22e8 disable_vga=1 disable_idle_d3=1
options zfs zfs_arc_max=13477347328
Code:
root@titan:~# cat /etc/pve/qemu-server/1000.conf #WINDOWS
agent: 1
balloon: 0
bios: ovmf
boot: order=scsi0;usb0
cores: 16
cpu: host
efidisk0: local-zfs:vm-1000-disk-0,efitype=4m,pre-enrolled-keys=1,size=1M
hostpci0: 0000:01:00,pcie=1
machine: pc-q35-10.0
memory: 65536
meta: creation-qemu=10.0.2,ctime=1756918785
name: WIN-TEMPLATE
net0: virtio=xx:xx:11:xx:21:F9,bridge=vmbr0,firewall=1
numa: 0
ostype: win11
parent: IDLE
scsi0: local-zfs:vm-1000-disk-1,cache=writeback,discard=on,iothread=1,size=64G,ssd=1
scsihw: virtio-scsi-single
smbios1: uuid=ab850xxb-1b2d-4xx65-axx7-316f27xxxxxx
sockets: 1
tpmstate0: local-zfs:vm-1000-disk-2,size=4M,version=v2.0
usb0: host=8564:1000,usb3=1
vga: none
vmgenid: efce54da-2664-xx8e-xx4b-afxxxxxxxxx
