VM untagged lan are unreacheable from network, the tagged ones works.

[Heracleos]

Hello everyone. I have a problem with the configuration of untagged VLANs on VMs, which are unable to reach the default untagged network.
My Proxmox nodes have a bond of two NICs dedicated specifically to VMs, and the configuration in /etc/network/interfaces is as follows:

auto bond1
iface bond1 inet manual
bond-slaves enp3s0f0 enp3s0f1
bond-miimon 100
bond-mode 802.3ad
bond-xmit-hash-policy layer2+3
#Vms_Bond

auto vmbr1
iface vmbr1 inet manual
bridge-ports bond1
bridge-stp off
bridge-fd 0
bridge-vlan-aware yes
bridge-vids 2-4094
#Vms_Lan

On the switch, I assigned the ports to the bond, in hybrid mode, with 1 as the default and a VLAN 128 for other uses.
When I assign vmbr1 to the VMs without any tag (and therefore it should work on the default untagged VLAN 1), it does not work and cannot reach the network.
The VMs, to which I assign tag 128, from proxmox gui configuration, work well.
It looks not to be a switch or network problem, because if I assign an IP to the Proxmox node on vmbr1, which belongs to the untagged network 1, I can ping and access the Proxmox console from my PC connected to the untagged network 1.
Basically, Proxmox does not pass untagged packets to the VMs.
Thanks to everyone who can help me.



[shanreich]

It's generally not advisable to mix tagged / untagged traffic and use VLAN 1. Would it just be possible to move your (management, I suppose?) untagged traffic to a dedicated VLAN (that is not 1)?



[Heracleos]

hello

It's generally not advisable to mix tagged / untagged traffic and use VLAN 1. Would it just be possible to move your (management, I suppose?) untagged traffic to a dedicated VLAN (that is not 1)?

Thanks for answering.
The Proxmox management is on another physical network, and on another untagged network specifically configured on the switch. So it's not something I'm concerned about.

The net for the vm is on a different bond with different physical net and switch, where the default untagged network 1 is used for a few VMs and tagged 128 vlan, for other vm. The Vlan 1 is untagged, and not tagged of course
