I have 3 nodes they have:
I would now like to get clients on my LAN to access ceph. however i cant get forwarding from the LAN > Mesh.
The actual client i am interested in doing this with is a VM on pve1. It has an address of 192.168.1.100 and xxxx:xxxx:830::<see the picture below>
From the VM i can ping both 10.0.0.81 and fc00::81 (same in the opposite direction).
From the VM if i try and ssh to fc00::81 it hangs and eventuall says connection reset by peer - i did a wirehshark and saw a single packet come back from fc00::81 - but no other packerts.
This tells me something really odd is going on, and i don't know what.
Yes kernel forwarding is turned on for both IPv4.
Yes SSHD is listening on :: and 0.0.0.0
Here is a wireshark from the client VM when i try to ssh into fc00::81.... (IPv4 has same symptoms)
Any one any ideas?
- public interfaces facing the LAN
- thunderbolt-net interfaces connected in a mesh
- ceph configured to use the mesh as its public and private networks
- for purposes of this scenario testing all firewalls on VMs
- Node1's private addresses are:
- 10.0.0.81/32
- fc00::81/128
- Node1s public addresses are:
- 192.168.1.81/24
- xxxx:xxxx:830::81/64
I would now like to get clients on my LAN to access ceph. however i cant get forwarding from the LAN > Mesh.
The actual client i am interested in doing this with is a VM on pve1. It has an address of 192.168.1.100 and xxxx:xxxx:830::<see the picture below>
From the VM i can ping both 10.0.0.81 and fc00::81 (same in the opposite direction).
From the VM if i try and ssh to fc00::81 it hangs and eventuall says connection reset by peer - i did a wirehshark and saw a single packet come back from fc00::81 - but no other packerts.
This tells me something really odd is going on, and i don't know what.
Yes kernel forwarding is turned on for both IPv4.
Yes SSHD is listening on :: and 0.0.0.0
Here is a wireshark from the client VM when i try to ssh into fc00::81.... (IPv4 has same symptoms)
Any one any ideas?
