Anybody know Mellanox?

SpongeRob

Member
Nov 29, 2021
20
4
23
Co. Donegal, Eire
Last edited:
So I've come across this IBM 10GB NIC, reportedly not compatible with Windows.
Anybody with any thoughts/suggestions please?
To make it PVE related: if the NIC runs under Debian it will probably work with Proxmox. Create a corresponding bridge, add that VM, install virtio drivers and... call it a day.

Disclaimer: have have zero Mellanox experience...

  • Like
Reactions: beisser
Probably it's a VM under PVE ;-)
not very likely. he didnt mention anything about pve, passthrough, or anything that would even hint at using pve.

to me it reads like "wahhh my stoneage-nic from 2009 doesnt work on modern windows, someone help"

i mean why would you passthrough a nic to windows 11 anyway?
to a firewall i could understand, but windows 11? what advantage is that supposed to give.

i dont think this is proxmox-related at all.
looks to me like he got lost and ended up on the wrong forums :)
Right, so I'm a small home user. I've just boiked my PCI-E server controller card, I need to wait till between Feb-Mar for that to arrive from China. I've a spare PC besides me, but only a spare 60GB SSD. I am far more knowledgeable using Windows over Linux, so my first thought in terms of testing this 10GB NIC was to bare metal it under Windows.

Ultimately I'm using the time before my new controller arrives to dry run this 10GB NIC that may ultimately end up in my ProxMox server (if I can get it working) so apologies that I haven't written my life story but I can definitely confirm this IS ProxMox related!

My next step then, is to install ProxMox on this 60GB SSD and experiment. However, I thought I'd ask the community in the hope of somebody knowing about these Mellanox NICs and being able to tell me about them. It was a long shot, I admit.

ok. i know mellanox as brand. its now called nvidia.
the network cards are generally good, some of the best even.
the model you are having is just ancient and EOL in terms of driver support. that means in windows anything after probably windows 7(10 at best, with some hack maybe) wont be able to use it. the last official drivers are for windows server 2008 r2 which equals windows 7.

linux driver support is generally much longer lived, so the chance of your card working on linux are generally higher, but even there development for the drivers most likely stopped a long time ago and its possible that the generic mellanox drivers dont support this card anymore.

i had a connect-x2 card which i used on windows 7 for a few years but ultimately discarded it when windows 10 came out as i couldnt make the old drivers work anymore.

googling around a bit it seems like the MT26448 cards are hit and miss depending on what kernel is used and what firmware is on the card.
specific to proxmox you can find people having issues after using pve 6.x or newer while the card worked fine on older versions (and thus older kernels).

you will have to try if you can still make it work, but my recommendation would be a newer, more modern card.
for example there are rj45 and sfp+ versions of the brand new realtek rtl8127 cards available for relatively little money(40-80€ new).
they are available as pcie4.0x1 or pcie3.0x4 cards (and even m.2) and are brand new.
chances are high that they will be supported by linux for a considerable amount of time to come.

otherwise second hand enterprise-nics are available as well under 100€, namely the connect-x4, intel x520/x540/x550/x710.
i have seen connect-x4 cards as cheap as 40€ on aliexpress.
those should all still be reasonably supported on current kernels.
